Corrugated Profile Roofing Sheet Roll Forming Machine With Hydraulic, PLC System

Name: Corrugated Profile Roofing Sheet Roll Forming Machine With Hydraulic PLC System
Brand: TECHWELL
Price: 1 USD

Place of Origin : China

Brand Name : TECHWELL

Certification : CE

Model Number : TW-RWM

MOQ : 1 Set

Price : Contact Us

Packaging Details : Standard packing

Delivery Time : 55-65 working days

Payment Terms : 40% T/T in advance, 60% T/T before shipment

Supply Ability : 20 sets

Material : PPGI, Color Steel, GI. Aluminium

Thickness : 0.3-0.8mm

Forming Stations : 16Stations ( Depend on Profiles )

Cutting type : Hydraulic cutting

Main power : 5.5KW

Cutting power : 3KW

Contact Now

Corrugated Profile Roofing Sheet Roll Forming Machine With Hydraulic, PLC System

A). Technical Specifications of Corrugated Roof Sheet Roll Former

Item	Corrugated Sheet Roll Forming Machine
Coil Material	Thickness	0.3-0.8mm
	Coil width	Custom-made, 1000mm or 1200mm or 1250mm
	Yield Strength	250-350 Mpa
	Material	PPGI, Color Steel, GI. Aluminium
Decoiler / Uncoiler	Decoiler Type	Manual or Hydraulic or Auto Type
	Coil Width	Max. 1250mm
	I.D	508-610mm
	O.D	Max. 1500mm
Corrugated Sheet Forming Machine	Forming Stations	16Stations ( Depend on Profiles )
	Roller material	45# steel, surface coated with 0.05mm hard chrome
	Diameter of shaft	76mm
	Shaft material	High grade 45# steel
	Drive type	Chain transmission
	Forming speed	0-15m/min
	Main power	5.5KW
Cutting System	Cutting type	Hydraulic cutting
	Cutting Die Material	Cr12Mov steel, HRC58-62
	Cutting power	3KW
	CuttingTolerance	10m+/-1.5mm
	Encoder	OMRON Brand
Electrical Control Board	PLC	PANASONIC Brand
	Inverter	YASKAWA Brand
	Touch screen	PANASONICE
	Operation type	Touch screen & Button
Hydraulic Station	Hydraulic station	Famous Chinese brand
Runout Tables	Table type	Simple nonpower type
Runout Tables	Function	To support the finished panels

B). Main Components of Corrugated Roof Sheet Roll Former

Decoiler / Uncoiler	1 Unit
Feeding Guide	1 Unit
Corrugated Sheet Roll Forming Machine	1 Unit
Hydraulic Cutting Device	1 Unit
Hydraulic Station	1 Unit
PLC Computer Control Board	1 Unit
Runout Tables	2 Units

C). Reference Profile Drawings of Corrugated Roof Sheet

Corrugated Profile Roofing Sheet Roll Forming Machine With Hydraulic, PLC System

D). Our advantages

High Quality
Reasonable Price
Good after Service
1 Year Warranty
Copra designing software
5-8 technicians every month specially do international installation and debugging
More Than 10 Years Experience

E). Reference Machine Pictures of Corrugated Roof Sheet Roll Former

Corrugated Profile Roofing Sheet Roll Forming Machine With Hydraulic, PLC System

F). More Contact Methosds

Company	Wuxi Techwell Machinery Co.,LTD
Website	www.cold-rollformingmachine.com
	www.roofrollformingmachine.com
	www.wxtechwell.com
Video	www.youtube.com/wxtechwell
Tel / Fax	0086-510-83133431
Mobile	0086-18018304331 ( Miss Lee )
E-Mail	monica@wxtechwell.com
Skype	monica198614
MSN	lixiaohua_monica@hotmail.com

G). FAQ

Q: Do you have after sales support?
A: Yes, we are happy to give advice and we also have skilled technicians available.

Q: Once we've bought a machine from you, are you able to supply us with material?
A: We can assist you in finding the appropriate materials to suit your machine.

Q: Do you sell only standard machines?
A: No, most of our machines are built according to customers specifications, using top brand name components.

Q: Do you have a warranty on your machines?
A: One year warranty excluding electrical components.

Q: Do you have instruction manuals?
A: We provide you with instruction manuals, electricity layouts, civil requirements, and machine drawings.

Q: Once a machine arrives at our factory what happens then?
A: We will send you a technician or engineer that will commission and install your machine, with training for your staff if required at a separate fee.
